Please contact us for more photos of SMCJ24CA-13-F
| Part Number | SMCJ24CA-13-F |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 851250 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode TVS Single Bi-Dir 24V 1.5KW 2-Pin SMC T R |
| Category | Circuit Protection |
| Family | TVS |
| ROHS Compliant | Yes |
| MSL Level | SMCJ24CA-13-F |
| Datasheet download |  SMCJ24CA-13-F.pdf |
| Part Number | SMCJ24CA-13-F |
|---|---|
| Lead Finish | Matte Tin |
| Minimum Breakdown Voltage | 26.7 V |
| Mounting | Surface Mount |
| Maximum Peak Pulse Current | 38.6 A |
| ESD Protection | No |
| Maximum Clamping Voltage | 38.9 V |
| Supplier Package | SMC |
| MSL Level | 1 |
| Product Dimensions | 7.11 x 6.22 x 2.3 mm |
| Peak Pulse Power Dissipation | 1500 W |
| Maximum Reverse Leakage Current | 5 uA |
| Test Current | 1 mA |
| Configuration | Single |
| Max Processing Temp | 260 |
| Operating Temperature | -55 to 150 °C |
| Direction Type | Bi-Directional |
| Pin Count | 2 |
| Rad Hard | No |
| Maximum Reverse Stand-off Voltage | 24 V |
| Package | 2SMC |
| Replacement Part Number | PART-SMCJ24CA-13-F |
| Weight | Contact us |
| Country of Origin | - |
