Please contact us for more photos of RK09K1130A5R
| Part Number | RK09K1130A5R |
|---|---|
| Manufacturer | ALPS |
| Quantity in stock | 643800 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res POT 10K Ohm 20% 1(Elec) 1(Mech)Turn 6mm (9.8 X 23.8mm) Pin Bracket Mount Through Hole |
| Category | Resistor |
| Family | Resistor Trimmers, Potentiometers and Rheostats |
| ROHS Compliant | Yes |
| MSL Level | RK09K1130A5R |
| Datasheet download |  RK09K1130A5R.pdf |
| Part Number | RK09K1130A5R |
|---|---|
| Termination Style | Pin |
| Package Type | |
| Operating Temperature | -10 to 70 °C |
| Mounting | Bracket Mount/Through Hole |
| Shaft Diameter | 6 mm |
| Product Dimensions | 9.8 x 23.8 mm |
| Resistance Value | 10 kOhm |
| Tolerance | 20 % |
| Number of Turns | 1(Elec)|1(Mech) Turns |
| Rad Hard | No |
| Type | Potentiometer |
| Product Height | 23.8 mm |
| Product Length | 9.8 mm |
| Replacement Part Number | PART-RK09K1130A5R |
| Weight | Contact us |
| Country of Origin | - |
