Please contact us for more photos of 10140702-0302K13LF
| Part Number | 10140702-0302K13LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 314820 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn DIMM Socket SKT 288 POS 0.85mm Solder ST SMD |
| Category | Connectors |
| Family | Connector Socket |
| ROHS Compliant | Yes |
| MSL Level | 10140702-0302K13LF |
| Datasheet download |  10140702-0302K13LF.pdf |
| Part Number | 10140702-0302K13LF |
|---|---|
| Rad Hard | No |
| Mounting | Surface Mount |
| Body Orientation | Straight |
| Gender | SKT |
| Contact Material | Copper Alloy |
| Lead Finish | Matte Tin Over Nickel |
| Pitch | 0.85 |
| Package Dimensions | 161.6 x 6.5 x 21.3 |
| Number of Contacts | 288 |
| Operating Temperature | -55 to 85 °C |
| Contact Plating | Gold Over Nickel |
| Housing Material | Thermoplastic |
| Number of Rows | 2 |
| Type | DIMM Socket |
| Termination Method | Solder |
| Pin Count | 288 |
| Product Depth | 6.5 |
| Product Height | 21.3 |
| Product Length | 161.6 |
| Replacement Part Number | PART-10140702-0302K13LF |
| Weight | Contact us |
| Country of Origin | - |
