Please contact us for more photos of 20020705-M031B01LF
| Part Number | 20020705-M031B01LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 735350 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Terminal Block 3 POS 7.62mm Solder ST Thru-Hole 30A Contact Box |
| Category | Connectors |
| Family | Connector Terminal Blocks |
| ROHS Compliant | Yes |
| MSL Level | 20020705-M031B01LF |
| Datasheet download |  20020705-M031B01LF.pdf |
| Part Number | 20020705-M031B01LF |
|---|---|
| Wire Size | 10 to 24 AWG |
| Contact Material | Copper/Steel |
| Product Dimensions | 23.46 x 12.5 x 21.5 mm |
| Pitch | 7.62 mm |
| Termination Method | Solder |
| Operating Temperature | -40 to 115 °C |
| Body Orientation | Straight |
| Housing Color | Green |
| Mounting | Through Hole |
| Rad Hard | No |
| Type | Terminal Block |
| Number of Rows | 1 |
| Contact Plating | Tin/Zinc |
| Housing Material | Thermoplastic |
| Product Depth | 12.5 mm |
| Product Height | 21.5 mm |
| Product Length | 23.46 mm |
| Replacement Part Number | PART-20020705-M031B01LF |
| Weight | Contact us |
| Country of Origin | - |
