Please contact us for more photos of 76347-302LF
| Part Number | 76347-302LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 437790 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Contact SKT Crimp ST Cable Mount Reel |
| Category | Connectors |
| Family | Connector Contacts |
| ROHS Compliant | Yes |
| MSL Level | 76347-302LF |
| Datasheet download |  76347-302LF.pdf |
| Part Number | 76347-302LF |
|---|---|
| Lead Finish | Matte Tin |
| Maximum Contact Resistance | 15 mOhm |
| Termination Method | Crimp |
| Shielded | No |
| Body Orientation | Straight |
| Product Dimensions | 11.56 x 2.1 x 2.6 mm |
| Wire Size | 22 to 30 AWG |
| Gender | SKT |
| Maximum Current Rating | 3 A |
| Contact Type | Signal |
| Connector Type | Connector Headers and PCB Receptacles |
| Contact Material | Phosphor Bronze |
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Series Name | DUBOX |
| Mounting | Cable Mount |
| Product Depth | 2.1 mm |
| Product Height | 2.6 mm |
| Product Length | 11.56 mm |
| Replacement Part Number | PART-76347-302LF |
| Weight | Contact us |
| Country of Origin | - |
