Please contact us for more photos of 85838-167LF
| Part Number | 85838-167LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 257690 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Hard Metric HDR 30 POS 2mm Press Fit ST Thru-Hole Tube |
| Category | Connectors |
| Family | Connector Backplane |
| ROHS Compliant | Yes |
| MSL Level | 85838-167LF |
| Datasheet download |  85838-167LF.pdf |
| Part Number | 85838-167LF |
|---|---|
| Termination Method | Press Fit |
| Package Dimensions | 11.93 x 17.8 x 17 mm |
| Maximum Current Rating | 1/Contact A |
| Pitch | 2 mm |
| Operating Temperature | -55 to 125 °C |
| Mounting | Through Hole |
| Lead Finish | Tin |
| Pin Count | 30 |
| Gender | HDR |
| Contact Plating | Tin |
| Body Orientation | Straight |
| Housing Material | Liquid Crystal Polymer |
| Type | |
| Number of Contacts | |
| Maximum Contact Resistance | |
| Number of Rows | |
| Maximum Voltage Rating | |
| Contact Material | Phosphor Bronze |
| Maximum Processing Temperature | 260 °C |
| Rad Hard | No |
| Product Depth | 17.8 mm |
| Product Height | 17 mm |
| Product Length | 11.93 mm |
| Replacement Part Number | PART-85838-167LF |
| Weight | Contact us |
| Country of Origin | - |
