Please contact us for more photos of 86130102323355E1LF
| Part Number | 86130102323355E1LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 551960 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Ejector Header HDR 10 POS 2.54mm Solder RA Thru-Hole Tray |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 86130102323355E1LF |
| Datasheet download |  86130102323355E1LF.pdf |
| Part Number | 86130102323355E1LF |
|---|---|
| Family | 8613 |
| Lead Free | Yes |
| Mounting | Through Hole |
| Operating Temperature | -55 to 125 °C |
| Maximum Voltage Rating | |
| Number of Contacts | |
| Maximum Current Rating | |
| Type | |
| Number of Rows | |
| Maximum Contact Resistance | |
| Pitch | 2.54 mm |
| Termination Method | Solder |
| Housing Material | Polyester |
| Gender | HDR |
| Contact Material | Copper Alloy |
| Housing Color | Gray |
| Body Orientation | Right Angle |
| Contact Plating | Gold Over Nickel Palladium |
| Packaging | Tray |
| Package Dimensions | 32 x 28 x 8.75 mm |
| Maximum Processing Temperature | 260 °C |
| Rad Hard | No |
| Lead Finish | Matte Tin Over Nickel |
| Pin Count | 10 |
| Product Depth | 28 mm |
| Product Height | 8.75 mm |
| Product Length | 32 mm |
| Replacement Part Number | PART-86130102323355E1LF |
| Weight | Contact us |
| Country of Origin | - |
