Please contact us for more photos of FA1-NESP-PCB-2
| Part Number | FA1-NESP-PCB-2 |
|---|---|
| Manufacturer | Amphenol |
| Quantity in stock | 876190 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn FAKRA PL 0Hz to 4GHz 50Ohm Solder ST Thru-Hole Gold |
| Category | Connectors |
| Family | Connector RF |
| ROHS Compliant | Yes |
| MSL Level | FA1-NESP-PCB-2 |
| Datasheet download |  FA1-NESP-PCB-2.pdf |
| Part Number | FA1-NESP-PCB-2 |
|---|---|
| Impedance | 50 Ohm |
| Terminate To | PCB |
| Body Orientation | Straight |
| Termination Method | Solder |
| Mounting | Through Hole |
| Type | FAKRA |
| Contact Plating | Gold |
| Contact Material | Brass |
| Package Dimensions | 12 x 10 x 14.3 mm |
| Gender | PL |
| Operating Frequency | 0 to 4 GHz |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Lead Finish | Gold |
| Product Depth | 10 mm |
| Product Height | 14.3 mm |
| Product Length | 12 mm |
| Replacement Part Number | PART-FA1-NESP-PCB-2 |
| Weight | Contact us |
| Country of Origin | - |
