Please contact us for more photos of HDB-15PFFS-SL8001
| Part Number | HDB-15PFFS-SL8001 |
|---|---|
| Manufacturer | Amphenol |
| Quantity in stock | 574750 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn High Density D-Sub F 15 POS Solder ST Panel Mount 15 Terminal 1 Port |
| Category | Connectors |
| Family | Connector D-Subminiature |
| ROHS Compliant | Yes |
| MSL Level | HDB-15PFFS-SL8001 |
| Datasheet download |  HDB-15PFFS-SL8001.pdf |
| Part Number | HDB-15PFFS-SL8001 |
|---|---|
| Mounting | Panel Mount |
| Gender | F |
| Contact Material | Copper Alloy |
| Pin Count | 15 |
| Contact Plating | Gold |
| Lead Finish | Gold |
| Body Orientation | Straight |
| Rad Hard | No |
| Termination Method | Solder |
| Operating Temperature | -20 to 105 °C |
| Housing Material | Nylon |
| Product Height | 21 mm |
| Product Length | 39.4 mm |
| Replacement Part Number | PART-HDB-15PFFS-SL8001 |
| Weight | Contact us |
| Country of Origin | - |
