Please contact us for more photos of 1944R-14M
| Part Number | 1944R-14M |
|---|---|
| Manufacturer | API Delevan |
| Quantity in stock | 664860 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind RF Molded Unshielded 1.2uH 20% 7.9MHz 45Q-Factor Phenolic 1A AXL T R |
| Category | Inductor |
| Family | Inductor Leaded |
| ROHS Compliant | Yes |
| MSL Level | 1944R-14M |
| Datasheet download |  1944R-14M.pdf |
| Part Number | 1944R-14M |
|---|---|
| Lead Style | Axial |
| Maximum DC Current | 1 A |
| Maximum Self Resonant Frequency | 176 MHz |
| Lead Finish | Tin |
| MSL Level | 1 |
| Protection Style | Molded/Unshielded |
| Operating Temperature | -55 to 125 °C |
| Package/Case | 4.9 X 11.35 |
| Product Dimensions | 11.35 mm |
| Test Frequency | 7.9 MHz |
| Type | RF |
| Inductance | 1.2 uH |
| Rad Hard | No |
| Core Material | Phenolic |
| Maximum DC Resistance | 280 mOhm |
| Tolerance | 20 % |
| Max Processing Temp | 260 |
| Minimum Quality Factor | 45@20MHz |
| Product Diameter | 4.9 mm |
| Product Length | 11.35 mm |
| Replacement Part Number | PART-1944R-14M |
| Weight | Contact us |
| Country of Origin | - |
