Please contact us for more photos of 009276008021106
| Part Number | 009276008021106 |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 685200 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Terminal Block F 8 POS 2.5mm Solder RA SMD 6A Contact T R |
| Category | Connectors |
| Family | Connector Terminal Blocks |
| ROHS Compliant | Yes |
| MSL Level | 009276008021106 |
| Datasheet download |  009276008021106.pdf |
| Part Number | 009276008021106 |
|---|---|
| Contact Plating | Tin Over Nickel |
| Contact Material | Beryllium Copper/Phosphor Bronze |
| Product Dimensions | 20 x 9 x 5 mm |
| Gender | F |
| Wire Size | 18 to 24 AWG |
| Max Processing Temp | 260 |
| Pitch | 2.5 mm |
| Rad Hard | No |
| Body Orientation | Right Angle |
| Mounting | Surface Mount |
| Housing Color | White |
| Housing Material | Nylon 46 |
| Lead Finish | Tin |
| Operating Temperature | -40 to 125 °C |
| Termination Method | Solder |
| Product Depth | 9 mm |
| Product Height | 5 mm |
| Product Length | 20 mm |
| Replacement Part Number | PART-009276008021106 |
| Weight | Contact us |
| Country of Origin | - |
