Please contact us for more photos of 06035A560JAT2A
| Part Number | 06035A560JAT2A |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 521990 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 56pF 50V C0G 5% SMD 0603 125\u00b0C Paper T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | 06035A560JAT2A |
| Datasheet download |  06035A560JAT2A.pdf |
| Part Number | 06035A560JAT2A |
|---|---|
| Case Size | 0603 |
| Product Dimensions | 1.6 x 0.81 x 0.9 mm |
| Rad Hard | No |
| Tolerance | 5 % |
| Dielectric | C0G |
| Lead Finish | Matte Tin |
| MSL Level | 1 |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Operating Temperature | -55 to 125 °C |
| Construction | Flat |
| Voltage(DC) | 50 V |
| Case Style | Ceramic Chip |
| Capacitance Value | 56 pF |
| Package/Case | 0603 |
| Product Depth | 0.81 mm |
| Product Height | 0.9(Max) mm |
| Product Length | 1.6 mm |
| Replacement Part Number | PART-06035A560JAT2A |
| Weight | Contact us |
| Country of Origin | - |
