Please contact us for more photos of 2225SC473MAT1A
| Part Number | 2225SC473MAT1A |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 433190 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 0.047uF 1500V X7R 20% SMD 2225 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | 2225SC473MAT1A |
| Datasheet download |  2225SC473MAT1A.pdf |
| Part Number | 2225SC473MAT1A |
|---|---|
| Operating Temperature | -55 to 125 °C |
| Rad Hard | No |
| Package/Case | 2225 |
| Tolerance | 20 % |
| MSL Level | 1 |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Voltage(DC) | 1.5 kV |
| Dielectric | X7R |
| Construction | Flat |
| Case Style | Ceramic Chip |
| Product Dimensions | 5.72 x 6.35 x 2.54 mm |
| Capacitance Value | 0.047 uF |
| Case Size | 2225 |
| Product Depth | 6.35 mm |
| Product Height | 2.54(Max) mm |
| Product Length | 5.72 mm |
| Replacement Part Number | PART-2225SC473MAT1A |
| Weight | Contact us |
| Country of Origin | - |
