Please contact us for more photos of CM03CG1R2C25AH
| Part Number | CM03CG1R2C25AH |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 536060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 1.2pF 25V C0G 0.25pF SMD 0201 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | CM03CG1R2C25AH |
| Datasheet download |  CM03CG1R2C25AH.pdf |
| Part Number | CM03CG1R2C25AH |
|---|---|
| Mounting | Surface Mount |
| Construction | Flat |
| Case Size | 0201 |
| Tolerance | 0.25 pF |
| Lead Finish | Tin Over Nickel |
| Maximum Processing Temperature | 250 °C |
| Case Style | Ceramic Chip |
| Operating Temperature | -55 to 125 °C |
| Military Standard | |
| Dielectric | |
| Failure Rate | |
| Supplier Package | 0201 |
| Package/Case | 0201 |
| Package Dimensions | 0.6 x 0.3 mm |
| Capacitance Value | 1.2 pF |
| Rad Hard | No |
| Pin Count | 2 |
| Voltage(DC) | 25 V |
| Termination Style | Wraparound |
| Product Depth | 0.3 mm |
| Product Length | 0.6 mm |
| Replacement Part Number | PART-CM03CG1R2C25AH |
| Weight | Contact us |
| Country of Origin | - |
