Please contact us for more photos of TCJB336M010R0200
| Part Number | TCJB336M010R0200 |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 516240 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 33uF 10V B CASE 20% (3.5 X 2.8 X 1.9mm) SMD 3528-21 0.2 Ohm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | TCJB336M010R0200 |
| Datasheet download |  TCJB336M010R0200.pdf |
| Part Number | TCJB336M010R0200 |
|---|---|
| Construction | Flat |
| Leakage Current | |
| Capacitance Value | 33 uF |
| Polarity | Polar |
| Lead Finish | Matte Tin |
| Military Standard | |
| Package/Case | 3528-21,B |
| Mounting | Surface Mount |
| Product Dimensions | 3.5 x 2.8 x 1.9 mm |
| Voltage(DC) | 10 V |
| MSL Level | 1 |
| Operating Temperature | -55 to 125 °C |
| Max Processing Temp | 250|260 |
| Dissipation Factor | |
| Equivalent Series Resistance | |
| Failure Rate | |
| Case Size | 3528-21 |
| Rad Hard | No |
| Tolerance | 20 % |
| Case Style | Molded |
| Case Code | B |
| Product Depth | 2.8 mm |
| Product Height | 1.9 mm |
| Product Length | 3.5 mm |
| Replacement Part Number | PART-TCJB336M010R0200 |
| Weight | Contact us |
| Country of Origin | - |
