Please contact us for more photos of TCJD157M010R0040
| Part Number | TCJD157M010R0040 |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 665700 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 150uF 10V D CASE 20% (7.3 X 4.3 X 2.9mm) SMD 7343-31 0.04 Ohm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | TCJD157M010R0040 |
| Datasheet download |  TCJD157M010R0040.pdf |
| Part Number | TCJD157M010R0040 |
|---|---|
| Package/Case | 7343-31,D |
| Leakage Current | |
| Polarity | Polar |
| Mounting | Surface Mount |
| Case Code | D |
| Product Dimensions | 7.3 x 4.3 x 2.9 |
| Voltage(DC) | 10 V |
| Lead Finish | Pure Tin |
| Operating Temperature | -55 to 125 °C |
| Construction | Flat |
| Dissipation Factor | |
| Equivalent Series Resistance | |
| Failure Rate | |
| Military Standard | |
| MSL Level | 3 |
| Case Size | 2917 |
| Capacitance Value | 150 uF |
| Pin Count | 2 |
| Supplier Package | 2917 |
| Max Processing Temp | 260 |
| Case Style | Molded |
| Tolerance | 20 % |
| Rad Hard | No |
| Product Depth | 4.3 mm |
| Product Height | 2.9 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-TCJD157M010R0040 |
| Weight | Contact us |
| Country of Origin | - |
