Please contact us for more photos of TPSE476K020R0150
| Part Number | TPSE476K020R0150 |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 314820 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 47uF 20V E CASE 10% (7.3 X 4.3 X 4.1mm) SMD 7343-43 0.15 Ohm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | TPSE476K020R0150 |
| Datasheet download |  TPSE476K020R0150.pdf |
| Part Number | TPSE476K020R0150 |
|---|---|
| Construction | Flat |
| Leakage Current | |
| Polarity | Polar |
| Mounting | Surface Mount |
| Voltage(DC) | 20 V |
| Product Dimensions | 7.3 x 4.3 x 4.1 mm |
| MSL Level | 1 |
| Operating Temperature | -55 to 125 °C |
| Case Size | 7343-43 |
| Package/Case | 7343-43,E |
| Capacitance Value | 47 uF |
| Lead Finish | Matte Tin |
| Failure Rate | |
| Equivalent Series Resistance | |
| Dissipation Factor | |
| Military Standard | |
| Case Code | E |
| Case Style | Molded |
| Tolerance | 10 % |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Product Depth | 4.3 mm |
| Product Height | 4.1 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-TPSE476K020R0150 |
| Weight | Contact us |
| Country of Origin | - |
