Please contact us for more photos of TPSE686M025R0200
| Part Number | TPSE686M025R0200 |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 483140 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 68uF 25V E CASE 20% (7.3 X 4.3 X 4.1mm) SMD 7343-43 0.2 Ohm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | TPSE686M025R0200 |
| Datasheet download |  TPSE686M025R0200.pdf |
| Part Number | TPSE686M025R0200 |
|---|---|
| Case Code | E |
| Case Style | Molded |
| Voltage(DC) | 25 V |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Tolerance | 20 % |
| Construction | Flat |
| Leakage Current | |
| Capacitance Value | 68 uF |
| Mounting | Surface Mount |
| Polarity | Polar |
| MSL Level | 1 |
| Product Dimensions | 7.3 x 4.3 x 4.1 mm |
| Case Size | 7343-43 |
| Operating Temperature | -55 to 125 °C |
| Lead Finish | Matte Tin |
| Package/Case | 7343-43,E |
| Failure Rate | |
| Equivalent Series Resistance | |
| Dissipation Factor | |
| Military Standard | |
| Product Depth | 4.3 mm |
| Product Height | 4.1 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-TPSE686M025R0200 |
| Weight | Contact us |
| Country of Origin | - |
