Please contact us for more photos of TPSY226M035S0200
| Part Number | TPSY226M035S0200 |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 228890 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 22uF 35V Y CASE 20% (7.3 X 4.3 X 2mm) SMD 7343-20 0.2 Ohm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | TPSY226M035S0200 |
| Datasheet download |  TPSY226M035S0200.pdf |
| Part Number | TPSY226M035S0200 |
|---|---|
| Pin Count | 2 |
| Military Standard | |
| Construction | Flat |
| Package Dimensions | 7.3 x 4.3 x 2 mm |
| Equivalent Series Resistance | 0.2 Ohm |
| Lead Finish | Pure Tin |
| Failure Rate | |
| Capacitance Value | 22 uF |
| Supplier Package | 2917 |
| Case Style | Molded |
| Voltage(DC) | 35 V |
| Rad Hard | No |
| Mounting | Surface Mount |
| Case Size | 2917 |
| Moisture Sensitivity Level | 1 |
| Leakage Current | 7.7@5Min uA |
| Polarity | Polar |
| Case Code | Y |
| Operating Temperature | -55 to 125 °C |
| Tolerance | 20 % |
| Package/Case | 7343-20,Y |
| Dissipation Factor | 6 % |
| Product Depth | 4.3 mm |
| Product Height | 2(Max) mm |
| Product Length | 7.3 mm |
| Product Weight | 0.223 G |
| Replacement Part Number | PART-TPSY226M035S0200 |
| Weight | Contact us |
| Country of Origin | - |
