Please contact us for more photos of 4609X-101-101LF
| Part Number | 4609X-101-101LF |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 748050 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film NET 100 Ohm 2% 1.13W \u00b1100ppm \u00b0C BUS Conformal 9-Pin SIP Pin Thru-Hole Bulk |
| Category | Resistor |
| Family | Resistor Networks and Arrays |
| ROHS Compliant | Yes |
| MSL Level | 4609X-101-101LF |
| Datasheet download |  4609X-101-101LF.pdf |
| Part Number | 4609X-101-101LF |
|---|---|
| Temperature Coefficient | ±100 ppm/°C |
| Lead Finish | Tin/Silver/Copper |
| Case Style | Conformal |
| Terminal Pitch | 2.54 mm |
| Power Rating per Resistor | 1/5 W |
| Mounting | Through Hole |
| Power Rating | 1.13 W |
| Max Processing Temp | 260 |
| Tolerance | 2 % |
| Resistance Value | 100 Ohm |
| Rad Hard | No |
| Operating Temperature | -55 to 125 °C |
| Technology | Thick Film |
| MSL Level | 1 |
| Product Dimensions | 22.81 x 2.49 x 5.08 mm |
| Termination Style | Pin |
| Product Depth | 2.49 mm |
| Product Height | 5.08 mm |
| Product Length | 22.81 mm |
| Replacement Part Number | PART-4609X-101-101LF |
| Weight | Contact us |
| Country of Origin | - |
