Please contact us for more photos of 4816P-1-102LF
| Part Number | 4816P-1-102LF |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 830380 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film NET 1K Ohm 2% 1.28W \u00b1100ppm \u00b0C ISOL Molded 16-Pin SOM Gull Wing SMD T R |
| Category | Resistor |
| Family | Resistor Networks and Arrays |
| ROHS Compliant | Yes |
| MSL Level | 4816P-1-102LF |
| Datasheet download |  4816P-1-102LF.pdf |
| Part Number | 4816P-1-102LF |
|---|---|
| Technology | Thick Film |
| Terminal Pitch | 1.27 mm |
| Product Dimensions | 11.18 x 7.62 x 2.16 mm |
| Mounting | Surface Mount |
| Tolerance | 2 % |
| Temperature Coefficient | ±100 ppm/°C |
| Power Rating per Resistor | 4/25 W |
| Lead Finish | Tin |
| Operating Temperature | -55 to 125 °C |
| MSL Level | 1 |
| Termination Style | Gull Wing |
| Resistance Value | 1 kOhm |
| Power Rating | 1.28 W |
| Rad Hard | No |
| Case Style | Molded |
| Max Processing Temp | 260 |
| Product Depth | 7.62 mm |
| Product Height | 2.16 mm |
| Product Length | 11.18 mm |
| Replacement Part Number | PART-4816P-1-102LF |
| Weight | Contact us |
| Country of Origin | - |
