Please contact us for more photos of CR0603-JW-101EZ2
| Part Number | CR0603-JW-101EZ2 |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 763280 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 0603 100 Ohm 5% 1 10W \u00b1200ppm \u00b0C Molded SMD Paper T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | CR0603-JW-101EZ2 |
| Datasheet download |  CR0603-JW-101EZ2.pdf |
| Part Number | CR0603-JW-101EZ2 |
|---|---|
| Mounting | Surface Mount |
| Package Dimensions | 1.6 x 0.8 x 0.45 mm |
| Operating Temperature | -55 to 155 °C |
| Case Size | 0603 |
| Temperature Coefficient | 200 ppm/°C |
| Resistance Value | 100 Ohm |
| Pin Count | 2 |
| Supplier Package | 0603 |
| Case Style | Molded |
| Rad Hard | No |
| Type | Thick Film |
| Tolerance | 5 % |
| Termination Style | Wraparound |
| Product Depth | 0.8 mm |
| Product Height | 0.45 mm |
| Product Length | 1.6 mm |
| Replacement Part Number | PART-CR0603-JW-101EZ2 |
| Weight | Contact us |
| Country of Origin | - |
