Please contact us for more photos of 100MT160PBPBF
| Part Number | 100MT160PBPBF |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 384630 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Rectifier Bridge Single 1.6KV 100A 7-Pin |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | 100MT160PBPBF |
| Datasheet download |  100MT160PBPBF.pdf |
| Part Number | 100MT160PBPBF |
|---|---|
| Peak Reverse Current | 5000 uA |
| Rad Hard | No |
| Configuration | Single |
| Peak Average Forward Current | 100 A |
| Product Dimensions | 63.5 x 32.5 x 16 mm |
| Pin Count | 7 |
| Peak Forward Voltage | 1.51 V |
| Peak Reverse Repetitive Voltage | 1600 V |
| Bridge Type | Three Phase |
| Peak Non-Repetitive Forward Surge Current | 470 A |
| Operating Temperature | -40 to 150 °C |
| Mounting | Screw |
| Package | 7 |
| Replacement Part Number | PART-100MT160PBPBF |
| Weight | Contact us |
| Country of Origin | - |
