ASMT-RF45-AN002 Broadcom

Please contact us for more photos of ASMT-RF45-AN002

Part Number	ASMT-RF45-AN002
Manufacturer	Broadcom
Quantity in stock	294080 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Yellow Green 574nm 2-Pin Chip LED T R
Category	Lighting
Family	LEDs
ROHS Compliant	Yes
MSL Level	ASMT-RF45-AN002
Datasheet download	ASMT-RF45-AN002.pdf

Request Quotation for ASMT-RF45-AN002

ASMT-RF45-AN002 Specifications

Part Number	ASMT-RF45-AN002
Max Processing Temp	255 to 260
Rad Hard	No
Lens Shape Type	Rectangular
Operating Temperature	-40 to 100 °C
Intensity	60 mcd
Number of LEDs	1
LED Material	AlGaInP
MSL Level	2a
Lens Appearance	Colorless Diffused
Supplier Package	Chip LED
Mounting	Surface Mount
Viewing Angle	145 °
Dominant Wavelength	573 nm
Mounting Orientation	Top Mount
Color	Yellow Green
Peak Wavelength	574 nm
Maximum Forward Voltage per Color	2.4 V
Maximum Power Dissipation	48 mW
Product Dimensions	1.6 x 0.8 x 0.45 mm
Pin Count	2
Maximum Forward Current	20 mA
Category	Chip LED
Reverse Voltage	5 V
Type	Uni-Color
Package	2Chip LED
Replacement Part Number	PART-ASMT-RF45-AN002
Weight	Contact us
Country of Origin	-
