HLMP-4700-C00B2 Broadcom

Please contact us for more photos of HLMP-4700-C00B2

Part Number	HLMP-4700-C00B2
Manufacturer	Broadcom
Quantity in stock	215120 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Red 635nm 2-Pin T-1 3 4
Category	Lighting
Family	LEDs
ROHS Compliant	Yes
MSL Level	HLMP-4700-C00B2
Datasheet download	HLMP-4700-C00B2.pdf

Request Quotation for HLMP-4700-C00B2

HLMP-4700-C00B2 Specifications

Part Number	HLMP-4700-C00B2
Lead Finish	Matte Tin
Lens Appearance	Colored Diffused
Viewing Angle	50 °
Product Dimensions	6.1 x 6.1 x 9.19 mm
Category	Standard LED
Lens Dimensions	5.08x5.08x8.3 mm
Number of LEDs	1
Operating Temperature	-40 to 100 °C
Reverse Voltage	5 V
Dominant Wavelength	626 nm
Intensity	2.3 mcd
Lens Shape Type	Circular
Maximum Power Dissipation	14 mW
Mounting	Through Hole
Maximum Forward Current	7 mA
Color	Red
LED Material	GaP
Rad Hard	No
Peak Wavelength	635 nm
Pin Count	2
Supplier Package	T-1 3/4
Maximum Forward Voltage per Color	2 V
Type	Uni-Color
Mounting Orientation	Right Angle
Max Processing Temp	250
Package	2T-1 3/4
Replacement Part Number	PART-HLMP-4700-C00B2
Weight	Contact us
Country of Origin	-
