HSMC-A100-R00J1 Broadcom

Please contact us for more photos of HSMC-A100-R00J1

Part Number	HSMC-A100-R00J1
Manufacturer	Broadcom
Quantity in stock	667790 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Red 626nm 2-Pin PLCC T R
Category	Lighting
Family	LEDs
ROHS Compliant	Yes
MSL Level	HSMC-A100-R00J1
Datasheet download	HSMC-A100-R00J1.pdf

Request Quotation for HSMC-A100-R00J1

HSMC-A100-R00J1 Specifications

Part Number	HSMC-A100-R00J1
Pin Count	2
Supplier Package	PLCC
Peak Wavelength	626 nm
Product Dimensions	3.2 x 2.8 x 1.8 mm
Maximum Forward Current	30 mA
Maximum Power Dissipation	63 mW
Max Processing Temp	245\|255 to 260
Mounting Orientation	Top Mount
Reverse Voltage	5 V
Rad Hard	No
Maximum Forward Voltage per Color	2.4 V
Lead Finish	Matte Tin
Operating Temperature	-55 to 100 °C
Viewing Angle	120 °
Number of LEDs	1
MSL Level	2a
Mounting	Surface Mount
Package	2PLCC
Replacement Part Number	PART-HSMC-A100-R00J1
Weight	Contact us
Country of Origin	-
