HSMN-A161-N00J1 Broadcom

Please contact us for more photos of HSMN-A161-N00J1

Part Number	HSMN-A161-N00J1
Manufacturer	Broadcom
Quantity in stock	705420 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Blue 468nm 2-Pin PLCC T R
Category	Lighting
Family	HB LEDs
ROHS Compliant	Yes
MSL Level	HSMN-A161-N00J1
Datasheet download	HSMN-A161-N00J1.pdf

Request Quotation for HSMN-A161-N00J1

HSMN-A161-N00J1 Specifications

Part Number	HSMN-A161-N00J1
Reverse Voltage	5 V
Pin Count	2
Dominant Wavelength	470 nm
Max Processing Temp	245\|260
Maximum Forward Current	30 mA
Type	Uni-Color
Peak Wavelength	468 nm
Operating Temperature	-55 to 100 °C
Maximum Power Dissipation	180 mW
Viewing Angle	120 °
Maximum Forward Voltage per Color	4.05 V
Intensity	50 mcd
Color	Blue
Product Dimensions	3.2 x 2.8 x 1.8 mm
Supplier Package	PLCC
Lead Finish	Matte Tin
Rad Hard	No
Mounting	Surface Mount
LED Material	InGaN
Number of LEDs	1
Mounting Orientation	Top Mount
Category	Chip LED
MSL Level	2a
Lens Shape Type	Circular
Package	2PLCC
Replacement Part Number	PART-HSMN-A161-N00J1
Weight	Contact us
Country of Origin	-
