HSMS-C191 Broadcom

Please contact us for more photos of HSMS-C191

Part Number	HSMS-C191
Manufacturer	Broadcom
Quantity in stock	142190 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Red 630nm 2-Pin Chip LED T R
Category	Lighting
Family	LEDs
ROHS Compliant	Yes
MSL Level	HSMS-C191
Datasheet download	HSMS-C191.pdf

Request Quotation for HSMS-C191

HSMS-C191 Specifications

Part Number	HSMS-C191
Intensity	10 mcd
Operating Temperature	-40 to 85 °C
Maximum Power Dissipation	52 mW
Maximum Forward Voltage per Color	2.6 V
Maximum Forward Current	25 mA
Lens Dimensions	1x0.8x0.3 mm
Type	Uni-Color
Color	Red
Category	Chip LED
Number of LEDs	1
Lens Shape Type	Rectangular
LED Material	GaP
Viewing Angle	170 °
Product Dimensions	1.6 x 0.8 x 0.8 mm
Max Processing Temp	255 to 260
MSL Level	2a
Reverse Voltage	5 V
Lens Appearance	Colorless Diffused
Mounting Orientation	Top Mount
Pin Count	2
Peak Wavelength	630 nm
Dominant Wavelength	626 nm
Supplier Package	Chip LED
Mounting	Surface Mount
Lead Finish	Gold
Rad Hard	No
Package	2Chip LED
Replacement Part Number	PART-HSMS-C191
Weight	Contact us
Country of Origin	-
