Please contact us for more photos of 74AHC244D,118
| Part Number | 74AHC244D,118 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 200090 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Buffer Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin SO T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | 74AHC244D,118 |
| Datasheet download |  74AHC244D,118.pdf |
| Part Number | 74AHC244D,118 |
|---|---|
| Bus Hold | No |
| Pin Count | 20 |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Maximum Operating Supply Voltage | 5.5 V |
| Number of Input Enables per Chip | 0 |
| Operating Temperature | -40 to 125 °C |
| Number of Channels per Chip | 8 |
| Supplier Package | SO |
| Input Signal Type | Single-Ended |
| Number of Inputs per Chip | 8 |
| Number of Elements per Chip | 2 |
| Product Dimensions | 13 x 7.6 x 2.45 mm |
| Lead Finish | Gold |
| Rad Hard | No |
| Polarity | Non-Inverting |
| Output Type | 3-State |
| Typical Operating Supply Voltage | 5 V |
| Propagation Delay Test Condition | 50 pF |
| Maximum High Level Output Current | -8 mA |
| Fabrication Technology | CMOS |
| Logic Family | AHC |
| Logic Function | Buffer/Line Driver |
| Minimum Operating Supply Voltage | 2 V |
| Number of Outputs per Chip | 8 |
| Number of Output Enables per Chip | 2 Low |
| Maximum Quiescent Current | 4 uA |
| Maximum Propagation Delay Time @ Maximum CL | 11.9@3V to 3.6V|[email protected] to 5.5V ns |
| Maximum Low Level Output Current | 8 mA |
| Max Processing Temp | 260 |
| Package | 20SO |
| Replacement Part Number | PART-74AHC244D,118 |
| Weight | Contact us |
| Country of Origin | - |
