Please contact us for more photos of 74LVC3G17DC,125
| Part Number | 74LVC3G17DC,125 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 897720 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Schmitt Trigger Buffer 3-CH Non-Inverting CMOS 8-Pin VSSOP |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | 74LVC3G17DC,125 |
| Datasheet download |  74LVC3G17DC,125.pdf |
| Part Number | 74LVC3G17DC,125 |
|---|---|
| Lead Finish | Gold |
| Number of Output Enables per Chip | 0 |
| Maximum Quiescent Current | 40 uA |
| Maximum Low Level Output Current | 32 mA |
| Number of Input Enables per Chip | 0 |
| Pin Count | 8 |
| Number of Outputs per Chip | 3 |
| Product Dimensions | 2.1 x 2.4 x 0.85 mm |
| Number of Inputs per Chip | 3 |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|[email protected]|2.7@5V ns |
| Number of Elements per Chip | 3 |
| Number of Channels per Chip | 3 |
| Typical Operating Supply Voltage | 1.8|2.5|3.3|5 V |
| Typical Quiescent Current | 0.1 uA |
| Rad Hard | No |
| Bus Hold | No |
| Input Signal Type | Single-Ended |
| Maximum High Level Output Current | -32 mA |
| Max Processing Temp | 260 |
| Polarity | Non-Inverting |
| Maximum Operating Supply Voltage | 5.5 V |
| Propagation Delay Test Condition | 50 pF |
| MSL Level | 1 |
| Tolerant I/Os | 5 V |
| Mounting | Surface Mount |
| Fabrication Technology | CMOS |
| Minimum Operating Supply Voltage | 1.65 V |
| Logic Family | LVC |
| Operating Temperature | -40 to 125 °C |
| Supplier Package | VSSOP |
| Logic Function | Schmitt Trigger Buffer |
| Package | 8VSSOP |
| Replacement Part Number | PART-74LVC3G17DC,125 |
| Weight | Contact us |
| Country of Origin | - |
