Please contact us for more photos of 74VHC273FT(BE)
| Part Number | 74VHC273FT(BE) |
|---|---|
| Manufacturer | Toshiba |
| Quantity in stock | 540180 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Flip Flop D-Type Pos-Edge 8-Element 20-Pin TSSOP |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | 74VHC273FT(BE) |
| Datasheet download |  74VHC273FT(BE).pdf |
| Part Number | 74VHC273FT(BE) |
|---|---|
| Supplier Package | TSSOP |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|11@5V ns |
| Minimum Operating Supply Voltage | 2 V |
| Rad Hard | No |
| Maximum High Level Output Current | -8 mA |
| Operating Temperature | -40 to 85 °C |
| Mounting | Surface Mount |
| Maximum Quiescent Current | 0.004 mA |
| Product Dimensions | 6.5 x 4.4 x 1 |
| Lead Finish | Gold Over Nickel Palladium |
| Propagation Delay Test Condition | 50 pF |
| Pin Count | 20 |
| Polarity | Non-Inverting |
| Screening Level | Industrial |
| Logic Function | D-Type |
| Package | 20TSSOP |
| Replacement Part Number | PART-74VHC273FT(BE) |
| Weight | Contact us |
| Country of Origin | - |
