| Part Number | SN74HC240N |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 782120 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Buffer Line Driver 8-CH Inverting 3-ST CMOS 20-Pin PDIP Tube |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | SN74HC240N |
| Datasheet download |  SN74HC240N.pdf |
| Part Number | SN74HC240N |
|---|---|
| Bus Hold | No |
| Screening Level | Commercial |
| Fabrication Technology | CMOS |
| Minimum Operating Supply Voltage | 2 V |
| Maximum Operating Supply Voltage | 6 V |
| Number of Channels per Chip | 8 |
| Maximum Low Level Output Current | 7.8 mA |
| Logic Family | HC |
| Number of Outputs per Chip | 8 |
| Number of Input Enables per Chip | 0 |
| Typical Operating Supply Voltage | 5 V |
| Output Type | 3-State |
| Number of Inputs per Chip | 8 |
| Number of Elements per Chip | 2 |
| Polarity | Inverting |
| Mounting | Through Hole |
| Input Signal Type | Single-Ended |
| Pin Count | 20 |
| Supplier Package | PDIP |
| Maximum Quiescent Current | 8 uA |
| Product Dimensions | 24.33 x 6.35 x 4.57 mm |
| Propagation Delay Test Condition | 150 pF |
| Maximum High Level Output Current | -7.8 mA |
| Lead Finish | Gold |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Maximum Propagation Delay Time @ Maximum CL | 150@2V|[email protected]|26@6V ns |
| Logic Function | Buffer/Line Driver |
| Number of Output Enables per Chip | 2 Low |
| Package | 20PDIP |
| Replacement Part Number | PART-SN74HC240N |
| Weight | Contact us |
| Country of Origin | - |
