Please contact us for more photos of SN74LV1T125DCKR
| Part Number | SN74LV1T125DCKR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 248880 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Buffer Driver 1-CH Non-Inverting 3-ST CMOS 5-Pin SC-70 T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | SN74LV1T125DCKR |
| Datasheet download |  SN74LV1T125DCKR.pdf |
| Part Number | SN74LV1T125DCKR |
|---|---|
| Tolerant I/Os | 5 V |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|6.5@5V ns |
| Lead Finish | Gold Over Nickel Palladium |
| Input Signal Type | Single-Ended |
| Output Type | 3-State |
| Fabrication Technology | CMOS |
| Propagation Delay Test Condition | 30 pF |
| Operating Temperature | -40 to 125 °C |
| Number of Outputs per Chip | 1 |
| Minimum Operating Supply Voltage | 1.6 V |
| Number of Elements per Chip | 1 |
| Logic Function | Buffer/Driver |
| Number of Output Enables per Chip | 1 |
| Logic Family | LV |
| Bus Hold | No |
| Rad Hard | No |
| Typical Operating Supply Voltage | 1.8|2.5|3.3|5 V |
| Maximum High Level Output Current | -8 mA |
| Number of Channels per Chip | 1 |
| Product Dimensions | 2.15(Max) x 1.4(Max) x 1(Max) |
| Maximum Quiescent Current | 1 uA |
| Number of Input Enables per Chip | 0 |
| Maximum Operating Supply Voltage | 5.5 V |
| Number of Inputs per Chip | 1 |
| Mounting | Surface Mount |
| Polarity | Non-Inverting |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Screening Level | Extended Industrial |
| Supplier Package | SC-70 |
| Maximum Low Level Output Current | 8 mA |
| Pin Count | 5 |
| Package | 5SC-70 |
| Replacement Part Number | PART-SN74LV1T125DCKR |
| Weight | Contact us |
| Country of Origin | - |
