74LVX3245MTCX Fairchild Semiconductor

74LVX3245MTCX Images

Please contact us for more photos of 74LVX3245MTCX

Part Number 74LVX3245MTCX
Manufacturer Fairchild Semiconductor
Quantity in stock 633660 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Bus XCVR Single 8-CH 3-ST 24-Pin TSSOP T R
Category Logic & Timing IC
Family Logic ICs
ROHS Compliant Yes
MSL Level 74LVX3245MTCX
Datasheet download 74LVX3245MTCX.pdf
Request Quotation for 74LVX3245MTCX

74LVX3245MTCX Specifications

Part Number 74LVX3245MTCX
Fabrication Technology CMOS
Number of Selection Inputs per Element 0
Input Level CMOS
Output Type 3-State
Logic Family LVX
Number of Input Enables per Element 0
Output Level CMOS
Maximum Propagation Delay Time @ Maximum CL [email protected]@5V ns
Lead Finish Gold
Typical Operating Supply Voltage 3.3/5 V
Maximum Operating Supply Voltage 3.6/5.5 V
Number of Elements per Chip 1
Minimum Operating Supply Voltage 2.7|4.5 V
Maximum Low Level Output Current 24 mA
Rad Hard No
Operating Temperature -40 to 85 °C
Number of Output Enables per Element 1 Low
Logic Function Bus Transceiver with Voltage Translation
Product Dimensions 7.8 x 4.4 x 0.95 mm
Pin Count 24
Number of Channels per Chip 8
Maximum Quiescent Current 8 uA
Bus Hold No
Number of Direction Control Inputs 1 Low/High
Propagation Delay Test Condition 50 pF
Polarity Non-Inverting
Mounting Surface Mount
Max Processing Temp 260
Supplier Package TSSOP
Maximum High Level Output Current -24 mA
Data Flow Direction Bi-Directional
MSL Level 1
Package 24TSSOP
Replacement Part Number PART-74LVX3245MTCX
Weight Contact us
Country of Origin -
