Please contact us for more photos of SN74LS245DWR
| Part Number | SN74LS245DWR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 412120 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Bus XCVR Single 8-CH 3-ST 20-Pin SOIC T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | SN74LS245DWR |
| Datasheet download |  SN74LS245DWR.pdf |
| Part Number | SN74LS245DWR |
|---|---|
| Maximum Propagation Delay Time @ Maximum CL | 12@5V ns |
| Output Type | 3-State |
| Number of Selection Inputs per Element | 0 |
| Rad Hard | No |
| Operating Temperature | 0 to 70 °C |
| Number of Output Enables per Element | 1 Low |
| Lead Finish | Gold |
| Max Processing Temp | 260 |
| Input Level | TTL |
| Maximum Operating Supply Voltage | 5.25 V |
| Polarity | Non-Inverting |
| Maximum High Level Output Current | -15 mA |
| Number of Elements per Chip | 1 |
| Number of Channels per Chip | 8 |
| Mounting | Surface Mount |
| Bus Hold | No |
| Maximum Low Level Output Current | 24 mA |
| Screening Level | Commercial |
| Fabrication Technology | Bipolar |
| Product Dimensions | 12.8 x 7.52 x 2.35 mm |
| Logic Family | LS |
| Number of Direction Control Inputs | 1 Low/High |
| Output Level | TTL |
| MSL Level | 1 |
| Minimum Operating Supply Voltage | 4.75 V |
| Number of Input Enables per Element | 0 |
| Pin Count | 20 |
| Typical Operating Supply Voltage | 5 V |
| Supplier Package | SOIC |
| Propagation Delay Test Condition | 45 pF |
| Data Flow Direction | Bi-Directional |
| Logic Function | Bus Transceiver |
| Package | 20SOIC |
| Replacement Part Number | PART-SN74LS245DWR |
| Weight | Contact us |
| Country of Origin | - |
