Please contact us for more photos of SN74LVC4245APWR
| Part Number | SN74LVC4245APWR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 893260 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Bus XCVR Single 8-CH 3-ST 24-Pin TSSOP T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | SN74LVC4245APWR |
| Datasheet download |  SN74LVC4245APWR.pdf |
| Part Number | SN74LVC4245APWR |
|---|---|
| MSL Level | 1 |
| Maximum Propagation Delay Time @ Maximum CL | [email protected] to 3.6V@5V ns |
| Minimum Operating Supply Voltage | 2.7|4.5 V |
| Input Level | LVTTL|TTL |
| Product Dimensions | 7.8 x 4.4 x 1 mm |
| Logic Family | LVC |
| Output Type | 3-State |
| Number of Channels per Chip | 8 |
| Data Flow Direction | Bi-Directional |
| Number of Direction Control Inputs | 1 Low/High |
| Logic Function | Bus Transceiver with Voltage Translation |
| Number of Selection Inputs per Element | 0 |
| Maximum Quiescent Current | 80 uA |
| Supplier Package | TSSOP |
| Maximum Operating Supply Voltage | 3.6/5.5 V |
| Typical Operating Supply Voltage | 3.3/5 V |
| Pin Count | 24 |
| Number of Elements per Chip | 1 |
| Fabrication Technology | CMOS |
| Bus Hold | No |
| Propagation Delay Test Condition | 50 pF |
| Tolerant I/Os | 5 V |
| Polarity | Non-Inverting |
| Screening Level | Commercial |
| Mounting | Surface Mount |
| Output Level | LVCMOS |
| Number of Output Enables per Element | 1 Low |
| Maximum High Level Output Current | -24 mA |
| Number of Input Enables per Element | 0 |
| Maximum Low Level Output Current | 24 mA |
| Lead Finish | Gold |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Package | 24TSSOP |
| Replacement Part Number | PART-SN74LVC4245APWR |
| Weight | Contact us |
| Country of Origin | - |
