SN74HC193N Texas Instruments

SN74HC193N Images

Please contact us for more photos of SN74HC193N

Part Number SN74HC193N
Manufacturer Texas Instruments
Quantity in stock 220060 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Counter Single 4-Bit Binary UP Down 16-Pin PDIP Tube
Category Logic & Timing IC
Family Logic ICs
ROHS Compliant Yes
MSL Level SN74HC193N
Datasheet download SN74HC193N.pdf
Request Quotation for SN74HC193N

SN74HC193N Specifications

Part Number SN74HC193N
Number of Elements per Chip 1
Type Binary
Triggering Type Positive-Edge
Minimum Operating Supply Voltage 2 V
Parallel Enable Input Yes
Operation Mode UP Counter|Down Counter
Typical Operating Supply Voltage 5 V
Maximum Operating Supply Voltage 6 V
Product Dimensions 19.3 x 6.35 x 4.57 mm
Mounting Through Hole
Maximum Propagation Delay Time @ Maximum CL 250@2V|[email protected]|43@6V ns
Number of Stages 4
Fabrication Technology CMOS
Supplier Package PDIP
Pin Count 16
Reset Type Asynchronous
Direction Type Bi-Directional
Number of Selection Inputs per Element 0
Logic Family HC
Terminal Count Output Yes
Number of Element Outputs 4
Number of Element Inputs 4
Logic Function Counter
Number of Count Input Enables 2
Rad Hard No
Operating Temperature -40 to 85 °C
Lead Finish Gold
Propagation Delay Test Condition 50 pF
Package 16PDIP
Replacement Part Number PART-SN74HC193N
Weight Contact us
Country of Origin -
