Please contact us for more photos of SN74HC595DR
| Part Number | SN74HC595DR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 152920 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Shift Register Single 8-Bit Serial to Serial Parallel 16-Pin SOIC T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | SN74HC595DR |
| Datasheet download |  SN74HC595DR.pdf |
| Part Number | SN74HC595DR |
|---|---|
| Number of Element Outputs | 9 |
| Fabrication Technology | CMOS |
| Number of Stages | 8 |
| Propagation Delay Test Condition | 150 pF |
| Direction Type | Uni-Directional |
| Minimum Operating Supply Voltage | 2 V |
| Reset Type | Asynchronous |
| Supplier Package | SOIC |
| Pin Count | 16 |
| Product Dimensions | 9.9 x 3.91 x 1.58 mm |
| Number of Element Inputs | 1 |
| Number of Count Input Enables | 0 |
| Parallel Enable Input | No |
| Terminal Count Output | No |
| Operation Mode | Serial to Serial/Parallel |
| Maximum Propagation Delay Time @ Maximum CL | 200@2V|[email protected]|34@6V ns |
| Logic Function | Shift Register |
| Output Type | 3-State |
| Typical Operating Supply Voltage | 5 V |
| Logic Family | HC |
| Number of Selection Inputs per Element | 0 |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Maximum Quiescent Current | 0.008 mA |
| Triggering Type | Positive-Edge |
| Mounting | Surface Mount |
| Lead Finish | Gold |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Maximum Operating Supply Voltage | 6 V |
| Number of Elements per Chip | 1 |
| Package | 16SOIC |
| Replacement Part Number | PART-SN74HC595DR |
| Weight | Contact us |
| Country of Origin | - |
