Please contact us for more photos of ICE3AR2280JZ
| Part Number | ICE3AR2280JZ |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 447060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Current Mode PWM Controller IC for SMPS 800V 7-Pin DIP Tube |
| Category | Power Management IC |
| Family | PWM Controllers |
| ROHS Compliant | Yes |
| MSL Level | ICE3AR2280JZ |
| Datasheet download |  ICE3AR2280JZ.pdf |
| Part Number | ICE3AR2280JZ |
|---|---|
| Fall Time | 30 ns |
| Pin Count | 7 |
| Operating Supply Voltage | 10.5 to 25 V |
| Maximum Duty Cycle | 75 % |
| Mounting | Through Hole |
| Supplier Package | PDIP |
| Rad Hard | No |
| Rise Time | 30 ns |
| Output Voltage | 800 V |
| Product Dimensions | 9.77(Max) x 6.6(Max) x 4.57(Max) |
| Operating Temperature | -25 to 130 °C |
| Number of PWM Outputs | 1 |
| On/Off Pin | No |
| Switching Frequency | 108 kHz |
| Lead Finish | Matte Tin |
| Adjustable Output | No |
| Package | 7PDIP |
| Replacement Part Number | PART-ICE3AR2280JZ |
| Weight | Contact us |
| Country of Origin | - |
