Please contact us for more photos of NCP1060AD060R2G
| Part Number | NCP1060AD060R2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 841360 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Current Mode PWM Controller 250mA 10-Pin SOIC T R |
| Category | Power Management IC |
| Family | PWM Controllers |
| ROHS Compliant | Yes |
| MSL Level | NCP1060AD060R2G |
| Datasheet download |  NCP1060AD060R2G.pdf |
| Part Number | NCP1060AD060R2G |
|---|---|
| Pin Count | 10 |
| Switching Frequency | 22 to 26 kHz |
| Supplier Package | SOIC |
| Output Current | 250 mA |
| Product Dimensions | 5(Max) x 4(Max) x 1.5(Max) |
| Number of PWM Outputs | 1 |
| Topology | Flyback|Buck |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Mounting | Surface Mount |
| Operating Supply Voltage | 14 V |
| Operating Temperature | -40 to 125 °C |
| On/Off Pin | No |
| Max Processing Temp | 260 |
| Adjustable Output | No |
| MSL Level | 1 |
| Package | 10SOIC |
| Replacement Part Number | PART-NCP1060AD060R2G |
| Weight | Contact us |
| Country of Origin | - |
