| Part Number | UC2845NG4 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 651850 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Current Mode PWM Controller 1A 8-Pin PDIP Tube |
| Category | Power Management IC |
| Family | PWM Controllers |
| ROHS Compliant | Yes |
| MSL Level | UC2845NG4 |
| Datasheet download |  UC2845NG4.pdf |
| Part Number | UC2845NG4 |
|---|---|
| Rad Hard | No |
| Pin Count | 8 |
| Lead Finish | Gold |
| Switching Frequency | 500 kHz |
| Maximum Duty Cycle | 50 % |
| Max Processing Temp | 300 |
| On/Off Pin | No |
| Rise Time | 50 ns |
| Product Dimensions | 9.81 x 6.35 x 4.57 mm |
| Fall Time | 50 ns |
| Operating Temperature | -40 to 85 °C |
| Output Current | 1000 mA |
| Adjustable Output | No |
| Mounting | Through Hole |
| Supplier Package | PDIP |
| Number of PWM Outputs | 1 |
| Package | 8PDIP |
| Replacement Part Number | PART-UC2845NG4 |
| Weight | Contact us |
| Country of Origin | - |
