Please contact us for more photos of UCC3810DWTR
| Part Number | UCC3810DWTR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 842060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Current Mode PWM Controller 1A 16-Pin SOIC T R |
| Category | Power Management IC |
| Family | PWM Controllers |
| ROHS Compliant | Yes |
| MSL Level | UCC3810DWTR |
| Datasheet download |  UCC3810DWTR.pdf |
| Part Number | UCC3810DWTR |
|---|---|
| On/Off Pin | Yes |
| MSL Level | 2 |
| Maximum Duty Cycle | 50 % |
| Pin Count | 16 |
| Number of PWM Outputs | 2 |
| Operating Temperature | 0 to 70 °C |
| Rad Hard | No |
| Lead Finish | Gold |
| Max Processing Temp | 260 |
| Switching Frequency | 1000 kHz |
| Mounting | Surface Mount |
| Adjustable Output | No |
| Rise Time | 20 ns |
| Output Current | 1000 mA |
| Supplier Package | SOIC |
| Product Dimensions | 10.28 x 7.52 x 2.35 mm |
| Fall Time | 30 ns |
| Package | 16SOIC |
| Replacement Part Number | PART-UCC3810DWTR |
| Weight | Contact us |
| Country of Origin | - |
