Please contact us for more photos of TIP110G
| Part Number | TIP110G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 545860 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans Darlington NPN 60V 2A 3-Pin(3+Tab) TO-220AB Rail |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | TIP110G |
| Datasheet download |  TIP110G.pdf |
| Part Number | TIP110G |
|---|---|
| Lead Finish | Matte Tin |
| Product Dimensions | 10.28 x 4.82 x 9.28 mm |
| Mounting | Through Hole |
| Pin Count | 3 |
| Maximum Collector Cut-off Current | 1000 uA |
| Minimum DC Current Gain | 1000@1A@4V|500@2A@4V |
| Maximum Collector Emitter Saturation Voltage | 2.5@8mA@2A V |
| Type | NPN |
| Rad Hard | No |
| Maximum Emitter Base Voltage | 5 V |
| Maximum Collector Base Voltage | 60 V |
| Configuration | Single |
| Supplier Package | TO-220AB |
| Maximum Collector Emitter Voltage | 60 V |
| Peak DC Collector Current | 2 A |
| Package | 3TO-220AB |
| Replacement Part Number | PART-TIP110G |
| Weight | Contact us |
| Country of Origin | - |
