Please contact us for more photos of PDTC123JT,215
| Part Number | PDTC123JT,215 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 851110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans Digital BJT NPN 50V 100mA 3-Pin TO-236AB T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | PDTC123JT,215 |
| Datasheet download |  PDTC123JT,215.pdf |
| Part Number | PDTC123JT,215 |
|---|---|
| Rad Hard | No |
| Pin Count | 3 |
| Mounting | Surface Mount |
| Minimum DC Current Gain | 100@10mA@5V |
| Lead Finish | Tin |
| Product Dimensions | 3 x 1.4 x 1 mm |
| Peak DC Collector Current | 100 mA |
| MSL Level | 1 |
| Operating Temperature | -65 to 150 °C |
| Supplier Package | TO-236AB |
| Maximum Collector Emitter Voltage | 50 V |
| Maximum Collector Emitter Saturation Voltage | [email protected]@5mA V |
| Max Processing Temp | 260 |
| Typical Input Resistor | 2.2 kOhm |
| Type | NPN |
| Configuration | Single |
| Package | 3TO-236AB |
| Replacement Part Number | PART-PDTC123JT,215 |
| Weight | Contact us |
| Country of Origin | - |
