PI5C3384LEX Diodes Incorporated

Please contact us for more photos of PI5C3384LEX

Part Number	PI5C3384LEX
Manufacturer	Diodes Incorporated
Quantity in stock	328520 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Bus Switch 2-Element CMOS 10-IN 24-Pin TSSOP T R
Category	Logic & Timing IC
Family	Bus Switch
ROHS Compliant	Yes
MSL Level	PI5C3384LEX
Datasheet download	PI5C3384LEX.pdf

Request Quotation for PI5C3384LEX

PI5C3384LEX Specifications

Part Number	PI5C3384LEX
Maximum High Level Output Current	-120 mA
Typical Operating Supply Voltage	5 V
Number of Inputs per Chip	10
Logic Function	Bus Switch
Maximum Operating Supply Voltage	5.25 V
Lead Finish	Matte Tin
Number of Outputs per Chip	10
Minimum Operating Supply Voltage	4.75 V
Rad Hard	No
Number of Elements per Chip	2
Mounting	Surface Mount
Max Processing Temp	260
Operating Temperature	-40 to 85 °C
MSL Level	1
Propagation Delay Test Condition	50 pF
Configuration	5 x 1:1
Maximum Propagation Delay Time @ Maximum CL	0.25@5V ns
Fabrication Technology	CMOS
Supplier Package	TSSOP
Product Dimensions	7.9 x 4.5 x 1.05 mm
Pin Count	24
Maximum On Resistance	10 Ohm
Maximum Low Level Output Current	120 mA
Package	24TSSOP
Replacement Part Number	PART-PI5C3384LEX
Weight	Contact us
Country of Origin	-
