Please contact us for more photos of ACJ2112P
| Part Number | ACJ2112P |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 165830 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Electromechanical Relay SPDT 20(NO) 10(NC)A 12VDC 180Ohm Through Hole |
| Category | Switches and Relays |
| Family | Relays |
| ROHS Compliant | Yes |
| MSL Level | ACJ2112P |
| Datasheet download |  ACJ2112P.pdf |
| Part Number | ACJ2112P |
|---|---|
| Operate Time | 10 ms |
| Maximum DC Voltage Rating | |
| AC Coil Voltage | |
| Coil Current | |
| Maximum Current Rating | |
| DC Coil Voltage | |
| Maximum Pick-Up Voltage | |
| Type | |
| Maximum Power Rating | |
| Maximum AC Voltage Rating | |
| Contact Arrangement | SPDT |
| Minimum Dropout Voltage | 0.8 Vdc |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Coil Resistance | 180 Ohm |
| Relay Construction | Non-Latching |
| Contact Material | Silver Alloy |
| Product Dimensions | 12.2 x 13.7 x 13.8 |
| Pin Count | 8 |
| Termination Style | Solder |
| Mounting | Through Hole |
| Product Depth | 13.7 mm |
| Product Height | 13.5 mm |
| Product Length | 12.2 mm |
| Replacement Part Number | PART-ACJ2112P |
| Weight | Contact us |
| Country of Origin | - |
