Please contact us for more photos of AGN200S06
| Part Number | AGN200S06 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 481910 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Electromechanical Relay DPDT 1A 6VDC 257Ohm Surface Mount |
| Category | Switches and Relays |
| Family | Relays |
| ROHS Compliant | Yes |
| MSL Level | AGN200S06 |
| Datasheet download |  AGN200S06.pdf |
| Part Number | AGN200S06 |
|---|---|
| Product Dimensions | 10.6 x 5.7 x 10 mm |
| Contact Material | Silver Palladium |
| Operate Time | 4 ms |
| Relay Construction | Non-Latching |
| Mounting | Surface Mount |
| Coil Resistance | 257 Ohm |
| Contact Arrangement | DPDT |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Minimum Dropout Voltage | 0.6 Vdc |
| Product Depth | 5.7 mm |
| Product Height | 10 mm |
| Product Length | 10.6 mm |
| Replacement Part Number | PART-AGN200S06 |
| Weight | Contact us |
| Country of Origin | - |
