Please contact us for more photos of ALQ124
| Part Number | ALQ124 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 894610 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Electromechanical Relay SPDT 10(NO) 3(NC)A 24VDC 1.44Kohm Through Hole |
| Category | Switches and Relays |
| Family | Relays |
| ROHS Compliant | Yes |
| MSL Level | ALQ124 |
| Datasheet download |  ALQ124.pdf |
| Part Number | ALQ124 |
|---|---|
| Maximum Current Rating | 10(NO)|3(NC) A |
| Maximum AC Voltage Rating | 250 V |
| Type | Power Relay |
| Product Dimensions | 20 x 10 x 16 |
| Contact Material | Silver/Nickel |
| Coil Resistance | 1.44 kOhm |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Contact Arrangement | SPDT |
| Pin Count | 4 |
| Operate Time | 20 ms |
| Relay Construction | Non-Latching |
| Mounting | Through Hole |
| Termination Style | PC Pin |
| Minimum Dropout Voltage | 1.2 Vdc |
| Product Depth | 10 mm |
| Product Height | 16 mm |
| Product Length | 20 mm |
| Replacement Part Number | PART-ALQ124 |
| Weight | Contact us |
| Country of Origin | - |
