Please contact us for more photos of DS2E-S-DC24V
| Part Number | DS2E-S-DC24V |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 501470 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Electromechanical Relay DPDT 2A 24VDC 2.88KOhm Through Hole |
| Category | Switches and Relays |
| Family | Relays |
| ROHS Compliant | Yes |
| MSL Level | DS2E-S-DC24V |
| Datasheet download |  DS2E-S-DC24V.pdf |
| Part Number | DS2E-S-DC24V |
|---|---|
| Coil Resistance | 2.88 kOhm |
| Product Dimensions | 20 x 9.9 x 9.9 mm |
| Minimum Dropout Voltage | 2.4 Vdc |
| Relay Construction | Non-Latching |
| Contact Material | Silver/Gold Clad |
| Operating Temperature | -40 to 70 °C |
| Supplier Package | DIP |
| Mounting | Through Hole |
| Operate Time | 10 ms |
| Contact Arrangement | DPDT |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Lead Finish | Tin/Silver/Copper |
| Product Depth | 9.9 mm |
| Product Height | 9.9 mm |
| Product Length | 20 mm |
| Replacement Part Number | PART-DS2E-S-DC24V |
| Weight | Contact us |
| Country of Origin | - |
