Please contact us for more photos of JS124FT
| Part Number | JS124FT |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 351780 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Electromechanical Relay SPDT 5ADC 10AAC 24VDC 1.6KOhm Through Hole |
| Category | Switches and Relays |
| Family | Relays |
| ROHS Compliant | Yes |
| MSL Level | JS124FT |
| Datasheet download |  JS124FT.pdf |
| Part Number | JS124FT |
|---|---|
| Maximum DC Voltage Rating | 100 V |
| Type | Power Relay |
| Maximum Power Rating | 150|2.5 W|kVA |
| Minimum Dropout Voltage | 2.4 Vdc |
| Relay Construction | Non-Latching |
| Coil Current | 60 mA |
| Product Dimensions | 22 x 16 x 16.4 mm |
| Operating Temperature | -40 to 70 °C |
| Mounting | Through Hole |
| Maximum Pick-Up Voltage | 4.2 Vdc |
| Maximum AC Voltage Rating | 250 V |
| Coil Resistance | 1.6 kOhm |
| Maximum Current Rating | 5DC|10AC A |
| Operate Time | 10 ms |
| AC Coil Voltage | |
| Contact Arrangement | SPDT |
| Contact Material | Silver Tin Oxide |
| Rad Hard | No |
| DC Coil Voltage | 6 V |
| Product Depth | 16 mm |
| Product Height | 16.4 mm |
| Product Length | 22 mm |
| Replacement Part Number | PART-JS124FT |
| Weight | Contact us |
| Country of Origin | - |
